Insulectro stocks, distributes and supports a full range of back up, entry, drill and router tooling products to support PCB manufacturing.
Insulectro provides complete drilling and routing solutions through our supply partners LCOA™ and Kyocera in design, product development, and high precision needs of backup, entry, drills, end mills, routers, specialty tools, and repoint services used in the manufacturing of printed circuit boards.
LCOA™ and Kyocera have been in Southern California since their inception and are industry leaders in their respective product offerings. Unique in the North American printed circuit board market, they can respond rapidly to all needs and challenges in the Drill and Routing areas.
Troubleshooting, new product design, and process optimization are just a few areas in which Insulectro can assist our customers in achieving world-class quality standards in conjunction with our supply partners.
LCOA™ Back Up
Superior HWQ (Hole Wall Quality) with increased stack height and extended tool life.
Excellent HWQ, with no phenolic resins, designed for PCBs with an emphasis on burr reduction.
Paper based backer with excellent HWQ and reduced temperatures and burrs.
Specialty products showing significantly reduced image transfer and burrs. Minimizes need to rework.
Highest hole location accuracy, reduced drill deflection, can increase drill capacity, used for all drill sizes.
Similar to Bullseye®, used for older generation equipment.
Engineered aluminum alloy with excellent HWQ, reduced burring and predictable performance.
Rigid product primarily used for flexible circuits.
Solid product used across all types of PCB's.
Medium Non-Undercut Drills.
Tapered Blind Via Non-Undercut Drills.
Large Non-Undercut Drills.
Flex Circuits Straight Non-Undercut Drills.
Back Non-Undercut Drills.
Short Flute Pilot Undercut Drills.
Two into One Hybrid Flute Undercut Drill.
Back Non-Undercut Drills.
Accuracy Oriented Non-Undercut Drills.
Reduced Deflection Non-Undercut Drills.
Chipbreaker Updraft Routers
Chipbreaker style updraft router designed for superior edge finish on external and internal cuts.
Low Fracture Updraft Routers
Chipbreaker style updraft router designed with a cutting force reduction geometry leading to minimal routed edge fracturing and superior edge finish.
Flash Updraft Routers
Chipbreaker style updraft router designed for high stack routing with superior edge finish on external cuts.
Cross Cut Updraft Routers
Diamond cut style updraft router designed for high productivity routing.
Gold Tab Premium Edge Routers
Multiple flute cutter designed for routing printed circuit board gold tab connectors and plated solder features.
One Flute End Mills for Soft Materials.
One Flute End Mills for Flexible Laminates.
Two Flute End Mills.
Two Flute End Mills for Flexible Laminates.
Three Flute Zero Helix No End style (Safe End) End Mills.
Three Flute End Mills for Clean Edges.
Four Flute End Mills.
Kyocera Scoring / Engraving
Two flute scoring tool available with specified scoring angle.
Four flute countersink tool with specified countersink angle.
